XCF and KYF Flotation is widely used for roughing, concentrating and reverse flotation of nonferrous metals that include copper, lead, zinc, nickel and molybdenum, ferrous metal, and nonmetallic minerals.
SCOPE OF APPLICATION:
It can be widely used in the separation of non-ferrous metals, ferrous metals, and non-metallic minerals, and is suitable for the roughing and sweeping operations of large and medium-sized flotation plants.
Product Description
XCF and KYF flotation machine are advanced air-inflation, mechanical agitation flotation devices. It is developed mainly reference the flotation devices that currently used in mines. It is designed fully considered about the flotation characters and processing conditions, absorb the advantages of mechanical agitation flotation cells, avoid the shortcomings and defects of the other devices.
Applied material：Copper sulfide, gold sulfide, zinc, lead, nickel, antimony, fluorite, tungsten, and other non-ferrous metals, ferrous metals, and nonmetals.
Features
Parameter
| Model | Volume (m³) |
Cell Size (mm) |
Impeller Diameter (mm) |
Impeller Speed (r/min) |
Capacity (m³/min) |
Motor Power (kw) |
Single Cell Weight (kg) |
|---|---|---|---|---|---|---|---|
| XCF/KYF | 1 | 1000×1000×1100 | 400/340 | 358/281 | 0.2-1 | 5.5/4/1.1 | 920/1056 |
| XCF/KYF | 2 | 1300×1300×1250 | 470/410 | 331/247 | 0.4-2 | 7.5/5.5/1.1 | 1158/1346 |
| XCF/KYF | 3 | 1600×1600×1400 | 540/480 | 266/219 | 0.6-3 | 11/7.5/1.5 | 2172/2074 |
| XCF/KYF | 4 | 1800×1800×1500 | 620/550 | 215/200 | 1.2-4 | 15/11/1.5 | 2375/2100 |
| XCF/KYF | 6 | 2050×2050×1750 | 620/550 | 215/200 | 3-6 | 15/11/1.5 | 3545/3278 |
| XCF/KYF | 8 | 2200×2200×1950 | 720/630 | 185/175 | 3-8 | 22/15/1.5 | 4142/3857 |
| XCF/KYF | 10 | 2400×2400×2100 | 760/660 | 185/175 | 3-10 | 22/15/1.5 | 4894/4334 |
| XCF/KYF | 16 | 2800×2800×2400 | 860/740 | 160 | 4-6 | 37/30/1.5 | 6928/7575 |
| XCF/KYF | 20 | 3000×3000×2700 | 910/780 | 160 | 4-20 | 37/30/1.5 | 9200/8240 |
| XCF/KYF | 24 | 3100×3100×2900 | 950/800 | 153 | 4-24 | 37/30/1.5 | 10819/9820 |
| XCF/KYF | 30 | 3500×3500×3025 | 880/900 | 140 | 10-30 | 45/37/1.5 | 14810/13820 |
| XCF/KYF | 38 | 3600×3600×3400 | 1050/880 | 138 | 10-38 | 45/45/1.5 | 16900/16300 |
| XCF/KYF | 40 | 3800×3800×3400 | 1050/1050 | 138 | 10-40 | 45/45/1.5 | 18790/17097 |
| XCF/KYF | 50 | 4400×4400×3500 | 1200/1030 | 134 | 10-40 | 90/75/1.5 | 22000/22000 |
