The jig belongs to gravity-based equipment, which can separate mineral based on differing of specific gravity. Saw-tooth wave jig mainly consists of three parts: main frame, driving set and jigging chamber.
SCOPE OF APPLICATION:
It is widely used in ore beneficiation & slag recovery of ores like manganese oxide, hematite, limonite, specula rite, pyrite, fluorite, barite, celestite, & slag like ferrochrome smelting slag, silica-manganese smelting slag, etc.
Product Description
Jig is the key equipment for heavy ore selection, which is widely used in the selection of gold, tin, tungsten, lead, zinc, antimony, manganese, diamond, iron ore, coal gangue and other minerals. There are many kinds of jigs, including diaphragm jigs, compound double action jigs, sawtooth wave jigs, etc.
Applied material: Metal ore, such as tungsten, gold placer, etc.
Features
Parameter
| Model | Stroke Coefficient | Stroke (mm) |
Frequency (Times/min) |
Feeding Size (mm) |
Processing Capacity (t/h) |
Water Consumption (t/h) |
Power (kw) |
|---|---|---|---|---|---|---|---|
| LTA55/2 | 0.5 | 0-25 | 250-350 | 8 | 1-5 | 4-20 | 1.5 |
| LTA1010/2 | 0.5 | 0-25 | 250-350 | 8 | 5-15 | 20-60 | 3 |
| LTA1515/2 | 0.5 | 0-50 | 200-300 | 10 | 30-50 | 100-140 | 5.5 |
| LTA2020/2 | 0.5 | 0-50 | 200-300 | 10 | 40-60 | 160-200 | 7.5 |
| FRT16-2 | 0.9 | 0-90 | 0-200 | 0-50 | 40-60 | 200 | 18.5 |
| Model | Sectional Form |
Number Of Columns |
Number Of Jigging Rooms |
Jig Area (㎡) |
Stroke Coefficient |
Stroke (mm) |
Frequency (Times/min) |
Processing Capacity (t/h) |
Power (kw) |
|---|---|---|---|---|---|---|---|---|---|
| AM-30 | rectangle | double – row | 4 | 2.574 | 0.47 | 0-50 | 130-160 | 10-15 | 3 |
