The batch mill is mainly used for the mixing and grinding of materials, with uniform product fineness and saving power. The grinding time can be adjusted according to the fineness of the grinding material. The batch ball mills can be used for both dry and wet grinding.
SCOPE OF APPLICATION:
Cement, silicate products, new building materials, refractories, chemical fertilizer, beneficiation of black and non-ferrous metals, glass ceramics, and other production industries.
Product Description
Ceramic ball mill has the characteristics of less investment, energy saving and electricity saving compared with similar products, novel structure, easy operation, safe use, stable and reliable performance, etc. It is suitable for mixing and grinding of ordinary and special materials. The user can choose the appropriate model, lining plate, and medium type according to the specific gravity and hardness of the material, and the production capacity and other factors. The lining plate can be made of ceramic, silica, rubber, and metal.
Applied Material ：Cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal, and glass ceramics, ore, and other raw materials.
Features
Parameter
| Model | Capacity (tons/time) |
Cylinder Speed (r/min) |
Motor Power (kw) |
Weight (t) |
|---|---|---|---|---|
| TCQ910×1120 | 0.2 | 36 | 5.5-11 | 2.6 |
| TCQ1200×1400 | 0.5 | 32 | 11-18.5 | 4.3 |
| TCQ1500×1800 | 1 | 28 | 15-22 | 7.5 |
| TCQ1800×2100 | 1.5 | 26 | 18.5-30 | 10.5 |
| TCQ2100x2100 | 2.5 | 22 | 22-37 | 14 |
| TCQ2200×2400 | 3 | 20 | 28-45 | 18 |
| TCQ2500×2900 | 5 | 16 | 37-55 | 26 |
| TCQ2800×3700 | 8 | 14.5 | 55-75 | 35 |
| TCQ3000×3700 | 10 | 14 | 75-90 | 46 |
| TCQ3200×4600 | 15 | 13.5 | 90-110 | 63 |
