To be applied to the dry preconcentration of high-grade and lean magnetite ore before grinding with the selected granularity. The finer the granularity is, the better the result is. Generally, large number of tailings can be discharged, and the grinding quality can be greatly enhanced. To be applied to dry separation and recycling of the lost magnetite from the abandoned tailings. To be applied to dry separation and recycling of ferromagnetic materials from the abandoned steel slag.
SCOPE OF APPLICATION:
This machine is widely used in pre-separating at magnetic separation plants, mining stope, slag treatment at steel mills, garbage disposal, refractory industries etc.
Product Description
Dry magnetic separators are used in the dry separation of ferromagnetic ores. These separators facilitate a more efficient milling and processing operation through an initial upgrade of the desired feed material, delivering a more productive plant for a lower cost per processed ton.
Applied material：Iron, ilmenite, limonite, hematite, magnetite, manganese, chrome ore, chromium, coal, manganese, copper, coltan ore etc.
Features
Parameter
| Cylinder diameter (mm) | 1050 | 900 | 750 | 600 | 400 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Cylinder Length (mm) | 1200 | 1800 | 2400 | 1200 | 1800 | 2400 | 1200 | 1800 | 2400 | 1200 | 1800 | 2400 | 600 | 900 | 1200 |
| Capacity (t/h) | 40-60 | 70-90 | 100-120 | 20-40 | 50-70 | 80-160 | 15-30 | 45-60 | 65-80 | 10-15 | 15-25 | 25-30 | 3-5 | 6-10 | 10-15 |
| Cylinder Speed (r/min) | 20-25 | 25-28 | 28-30 | 35-40 | 40-45 | ||||||||||
| Gylinder Surface Magnetic Field GS | 1500-6000 | 1500-6000 | 1500-6000 | 1500-6000 | 1500-6000 | ||||||||||
| Motor Power (kw) | 7.5-5.5 | 5.5-4 | 4-3 | 3 | 1.5-2 | ||||||||||
