Wet Magnetic separator is one of the most used in the industry, and it is suitable for separating materials which have magnetism differences.
SCOPE OF APPLICATION:
This machine is widely used in mineral processing, coal washing and chemical industries for strong magnetic minerals. It often processes strongly magnetic materials such as magnetite, magnetic pyrite etc.
Product Description
Wet magnetic separator for separating strong magnetic minerals，which can be used for recovery of fine and strong magnetic minerals or removal of small amounts of ferromagnetic materials from non-magnetic minerals. And hongji magnetic separator is suitable for beneficiation of magnetite, pyrrhotite, hematite, limonite, siderite, etc.
Applied material: Mining Iron, Beneficiation Of Magnetite, Pyrrhotite, Hematite, Limonite, Siderite, Etc.
Features
Parameter
| Model | Cylinder Size (mm) |
Capacity (m³/h) |
Motor Power (kw) |
Drum Speed (r/min) |
Weight (kg) |
|
|---|---|---|---|---|---|---|
| (t· h) | (m³·h) | |||||
| CTS/CTN/CTB-69 | 600×900 | 8-15 | 24 | 1.1 | 40 | 780 |
| CTS/CTN/CTB-612 | 600×1200 | 10-20 | 32 | 2.2 | 40 | 990 |
| CTS/CTN/CTB-618 | 600×1800 | 15-30 | 48 | 2.2 | 40 | 1330 |
| CTS/CTN/CTB-712 | 750×1200 | 15-30 | 48 | 3 | 35 | 1500 |
| CTS/CTN/CTB-718 | 750×1800 | 20-45 | 72 | 3 | 35 | 2100 |
| CTS/CTN/CTB-918 | 900×1800 | 25-55 | 90 | 4 | 28 | 2500 |
| CTS/CTN/CTB-924 | 900×2400 | 35-70 | 110 | 4 | 28 | 2500 |
| CTS/CTN/CTB-1024 | 1050×2400 | 52-100 | 160 | 5.5 | 22 | 5000 |
| CTS/CTN/CTB-1030 | 1050×3000 | 65-125 | 200 | 7.5 | 19 | 5800 |
| CTS/CTN/CTB-1224 | 1200×2400 | 52-100 | 160 | 5.5 | 19 | 6200 |
| CTS/CTN/CTB-1230 | 1200×3000 | 82-120 | 192 | 7.5 | 19 | 7200 |
| CTS/CTN/CTB-1530 | 1500×3000 | 90-170 | 270 | 11 | 14 | 9700 |
| CTS/CTN/CTB-1540 | 1500×4000 | 115-220 | 350 | 11 | 14 | 11800 |
