Agitation scrubber used for dispersing the mineral mud, removing, and washing the impurities on mineral surface.
SCOPE OF APPLICATION:
It is mainly used for the dispersion of ore slime and the removal of impurities on the mineral surface，natural or artificial sand, various loose mud particles or materials.
Product Description
The agitation scrubber is for dispersing sludge, removing, and scrubbing impurities from mineral surfaces. The high-efficiency stirring scrubbing machine is suitable for natural or artificial sand with a mineral particle size of 0-6mm, various loose mud particles or materials. Solvents and soils on mineral or material surfaces.
Applied material：Silicon carbide, Mullite, Limestone, Barite Albite Feldspar, Wollastonite, Dolomite, Calcite, Limestone, iron and gold ore etc.
Features
Parameter
| Model | Effective Volume (m³) |
Shape | lmpeller | Electric Motor | Weight (kg) |
|||
|---|---|---|---|---|---|---|---|---|
| Diameter (mm) |
Speed (r/min) |
Model | Power (kw) |
Speed (r/min) |
||||
| GJCx1.5 | 1.5 | Hexahedron | Φ750 | 197 | Y200L-4 | 30 | 1480 | 1469 |
| GJCx2.8 | 2.8 | Φ1000 | 148 | Y250M-4 | 55 | 4030 | ||
| GJCx4.4 | 4.4 | Φ1000 | 148 | Y280S-4 | 70 | 6200 | ||
