Belt Conveyor, rubber-fiber-metal composite, for carrying and conveying materials. It is commonly used when material that is either stockpiled or loaded in a bin or hopper needs to be introduced into the system at a controlled feed rate.
SCOPE OF APPLICATION:
Clinker and other raw materials for Cement Plants, Coal Handling for Power Plants, Woodchip and Bark Handling for Pulp/Paper Mills, Sludge Handling for Process Applications.
Rail Unloading/Loadout, Bulk Warehousing of Granular Products, Sand Conveying Systems for Foundries, etc.
Product Description
Belt conveyor has the character of strong transport capacity, The conveyor belt can be used for horizontal or inclined transport, long transport distance, simple and easy to maintain, easy to implement automated operation. According to the requirements of the conveyor process, it can be a single conveyor, also several components or combined with other transport equipment to form a horizontal or inclined transport system to fit the different layout of the production line. It is widely used in metallurgy, cement, coal, chemicals, building materials, food, ports, and other fields.
Applied material: Mines, metallurgy, coal, coking, ports, electricity, building materials, grain, etc.
Features
Parameter
| Model | Conveyor Belt | Delivery Length (mm) |
Electric Drum Diameter (mm) |
Capacity (t/h) |
Power (kw) |
||
|---|---|---|---|---|---|---|---|
| Width (mm) |
Speed (m/s) |
inclination (°) |
|||||
| TB-500 | 500 | 0.8~2.5 | 0~20 | 20~240 | 500、630 | 40~230 | 1.5~30 |
| TB-650 | 650 | 0.8~2.5 | 0~20 | 20~240 | 500、630 | 67~391 | 1.5~45 |
| TB-800 | 800 | 0.8~3.15 | 0~20 | 20~240 | 500、630 | 118~824 | 2.2~75 |
| TB-1000 | 1000 | 1~3.15 | 0~20 | 20~240 | 500、630、800 | 230~1233 | 4~110 |
| TB-1200 | 1200 | 1~3.15 | 0~20 | 20~240 | 500、630、800 | 300~1600 | 5.5~130 |
| TB-1400 | 1400 | 1~3.15 | 0~20 | 20~240 | 630、800、1000 | 400~2000 | 7.5~160 |
| TB-1600 | 1600 | 1~3.15 | 0~20 | 20~240 | 630、800、1000 | 500~2300 | 11~220 |
