This bucket elevator adopts inflow feeding, which is used to convey powder, granular and small bulk materials vertically, such as coal, cement, stones, sand, clay and so on, it has the advantages of high capacity, lower power, reliable operation, air-proof, widely using range, high lifting height, long service life.
SCOPE OF APPLICATION:
Bucket elevators are widely used in food, medical, chemical, mining, metallurgy, building materials, coal, cement, Power, Potash, and hydropower industries.
Product Description
Bucket conveyors specialize in vertical conveying of large amounts of material ranging from heavy iron ore pellets to sand, fly ash and other dusty, powdery, dry material. Our bucket elevators are available with your choice of centrifugal or continuous discharge in belt or chain to best suit your specific application in multiple industries.
Applied material：Aggregates, Animal Feeds, Calcined Coke, Coal, Fertilizer, Fly ash, Frac Sand, Minerals, Potash, Lime, cement, etc.
Features
Parameter
| Model | TD250 | TD315 | TD400 | TD500 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Hopper Type | Q | H | Zd | Sd | Q | H | Zd | Sd | Q | H | Zd | Sd | Q | H | Zd | Sd |
| Capacity (m³/h) |
20 | 36 | 38 | 59 | 28 | 50 | 42 | 67 | 40 | 76 | 68 | 10 | 63 | 116 | 96 | 154 |
| Hopper Volume (L) |
1.1 | 2.2 | 3 | 4.6 | 1.9 | 3.5 | 3.7 | 5.8 | 3.1 | 5.6 | 5.9 | 9.4 | 4.8 | 9 | 9.3 | 14 |
| Hopper Speed (m/s) |
1.6 | 1.8 | ||||||||||||||
| Sprocket Speed (r/min) |
61 | 55 | ||||||||||||||
| Model | Max Llifting Height (m) |
Conveying Capacity (m³/h) |
Max Size Of Material (mm) |
Bucket Distance (mm) |
Motor Power (kw) |
|---|---|---|---|---|---|
| TH160 | 25 | 7-12 | 15-20 | 400 | 3-4 |
| TH200 | 28 | 8-15 | 20-30 | 500 | 3-5.5 |
| TH250 | 30 | 10-25 | 25-35 | 500 | 4-7.5 |
| TH300 | 30 | 25-35 | 30-40 | 500 | 5.5-11 |
| TH315 | 40 | 30-40 | 35-45 | 512 | 5.5-15 |
| TH400 | 40 | 45-60 | 40-55 | 512 | 11-22 |
| TH500 | 40 | 65-80 | 50-60 | 512 | 15-30 |
| TH630 | 40 | 100-120 | 60-65 | 688 | 18.5-37 |
| Model | Conveying Capacity (m³/h) |
Bucket Speed (m/s) |
Shaft Speed (r/min) |
Material Size (mm) |
Hopper |
||
|---|---|---|---|---|---|---|---|
| Volume (L) |
Bucket Width (mm) |
Bucket Distance (mm) |
|||||
| NE15 | 15 | 0.5 | 15.54 | <40 | 2.5 | 250 | 203 |
| NE30 | 32 | 16.45 | <50 | 7.8 | 300 | 305 | |
| NE50 | 60 | 16.45 | <50 | 15.7 | 300 | 305 | |
| NE100 | 110 | 14.13 | <70 | 35 | 400 | 400 | |
| NE150 | 170 | 14.13 | <70 | 52.2 | 600 | 400 | |
| NE200 | 210 | 10.9 | <100 | 84.6 | 600 | 500 | |
| NE300 | 320 | 10.9 | <100 | 127.5 | 600 | 500 | |
| NE400 | 380 | 8.3 | <120 | 182.5 | 700 | 600 | |
| NE500 | 470 | 7.1 | <120 | 260.9 | 700 | 700 | |
| NE600 | 600 | 7.1 | <120 | 330.2 | 700 | 700 | |
| NE800 | 800 | 6.2 | <140 | 501.8 | 800 | 800 | |
