The Screw Conveyor is most suitable for transporting all kinds of powder, granular materials. lumpish materials, such as coal, sand, lump coal, cement, cereal, etc. Perishable, viscous, easy caking materials are not available to transport.
SCOPE OF APPLICATION:
Construction, oil and gas, mining, chemical, pharmaceutical, plastic, food processing and agricultural.
Product Description
Screw conveyor is used in many industries, such as building materials, chemical engineering, coal, grain and oil, fodder. It is suitable for horizontal or inclined conveyor powdery, granulose, and small block material, such as grain, dinas, coal, flour, cement, chemical fertilizer and so on. It can’t convey material which is easy to metamorphic, sticky, agglomeration; Using temperature of environment is -20-~50°C, conveying material temperature is $200°C.
Applied material：Lead oxide, coal, grain and oil, fodder, grain, dinas, coal, flour, cement, chemical, fiberglass, fertilizer, gypsum, and so on.
Features
Parameter
| Model | Main Technical Performance | Drive | Drive | Weight (kg) |
|||
|---|---|---|---|---|---|---|---|
| Reducer | Electric Motor | ||||||
| Diameter (mm) |
Length (m) |
Capacity(Cement) (t/h) |
Rotating Speed (r/min) |
Model | Speed Ratio | Power (kw) |
|
| GX200 | -10 | 9 | 60 | 250 | 23.34 | 1.1 | 726 |
| GX200 | -20 | 9 | 60 | 250 | 23.34 | 1.5 | 1258 |
| GX250 | -10 | 15.6 | 60 | 250 | 23.34 | 2.2 | 960 |
| GX250 | -20 | 15.6 | 60 | 250 | 23.34 | 3 | 1750 |
| GX300 | -10 | 21.2 | 60 | 350 | 23.34 | 3 | 1373 |
| GX300 | -20 | 21.2 | 60 | 350 | 23.34 | 4 | 2346 |
| GX400 | -10 | 51 | 60 | 400 | 23.34 | 5.5 | 1911 |
| GX400 | -20 | 51 | 60 | 500 | 23.34 | 11 | 2049 |
| GX500 | -10 | 87.5 | 60 | 400 | 23.34 | 7.5 | 2381 |
| GX500 | -20 | 87.5 | 60 | 650 | 23.34 | 18.5 | 5389 |
| GX600 | -10 | 134.2 | 45 | 750 | 23.34 | 22 | 3880 |
| GX600 | -10 | 134.2 | 45 | 350 | 23.34 | 55 | 7090 |
